Spark™

Product Overview
IgniteNet™’s Spark™ AC is the most cost-effective, cloud-managed 802.11ac access point on the market. The Spark™ AC contains 2 independent, concurrent operation radios - one 802.11ac (5GHz) radio and one 802.11n (2.4GHz) radio - capable of delivering blisteringly fast wireless speeds. The ultra-small size of the Spark™ AC allows it to be placed inconspicuously in both offices and homes, bringing fast wireless connections to hard-to-reach locations.

Key Features and Benefits

Cloud Enabled Networking
The IgniteNet™ Spark™ AC is cloud?enabled out of the box allowing for easy, highly scalable installation, configuration, and management.

Dual Band AC750 Operation
The Spark™ AC is capable of operating simultaneously at 2.4GHz (802.11b/g/n) as well as 5GHz (802.11a/n/ac) to supply ample throughput for the most demanding applications.

Powerful, Flexible Configuration
The Spark™ AC can operate either as a stand-alone access point or as a coordinated, cloud-managed access point, easily meeting the requirements of any installation.

Robust Yet Simple Mounting Options
The Spark™ AC can be wall, ceiling, or desktop mounted, greatly simplifying installations in both offices and homes.

Features

HARDWARE FEATURES
✓ 1x Gigabit Ethernet Port (PoE IN)
✓ 2x 10/100 Fast Ethernet Ports
✓ 1x USB 2.0 Port
✓ Dual flash image support

LEDs
✓ Power, Ethernet, Wireless, Health/Status, Controller Status

DIMENSIONS (L x W x H )
✓ 120 x 120 x 25 mm

WEIGHT
✓ TBD g

POWER
✓ 12V/1A DC
✓ Passive Power over Ethernet
✓ 802.3af (Power over Ethernet (3AF model only)

OPERATING-ENVIRONMENT
✓ Operating Temperature: 0Cº to +50Cº
✓ Store Temperature: -40Cº to 70Cº
✓ Operating Humidity: 10 to 90% non-condensing (RH)

REGULATORY / STANDARDS COMPLIANCE
✓ FCC/IC
✓ CE

RF PERFORMANCE (TX)
✓ 2.4GHz:
27dBm @ 6Mbps, 23dBm @ 300Mbps
✓ 5GHz (AC750 models)only :
23dBm @ 6Mbps, 19dBm @ 433Mbps

RF PERFORMANCE (RX)
✓ 2.4GHz:
TBD
✓ 5GHz:
TBD

KEY-FEATURES
✓ Supports Service Provider and Enterprise type networks
✓ Stand-alone or Cloud-controlled operating modes
✓ AP/Client/Client WDS modes with Flexible Bridging and Routing
✓ 802.11a/n/ac 1x1 (AC750 models only) + 802.11b/g/n 2x2, Dual Band Dual Concurrent ( 2.4GHz and 5GHz)
✓ Supports up to 8 SSIDs per radio
✓ IEEE802.e Wi-Fi Multimedia (WMM-QoS)
✓ WEP, WPA,WPA2-PSK,WPA2-AES, PSK and Enterprise
✓ Admission control by client MAC address
✓ Supports bandsteering and assisted roaming

APPLICATIONS
✓ Enterprise AP
✓ 3G/4G Offload
✓ Managed WiFi Services
✓ Managed Home/SMB Gateway
