| Model |
ECS4620-52P |
| RJ-45 10/100/1000 Ports |
48 |
| 100/1000 SFP Ports |
0 |
| 10/100/1000 Combom Ports |
0 |
| SFP+ 10 Gigabit Uplink Ports |
2 |
| 10G SFP+ Expansion Module Slots |
1 |
| RJ-45 Console Port |
Yes |
| Switching Capacity |
176 Gbps |
| Forwarding Rate |
130.94Mpps |
| Flash Memory |
128 MB |
| DRAM |
256 MB |
| MAC Address Table |
16 K |
| Jumbo Frames |
10 K |
| Auto-negotiation, Auto-MDI/MDIX |
Yes |
| Support on all Gigabit ports based on IEEE 802.3af |
Yes |
| PoE+ based on IEEE 802.3at |
Yes |
| Auto disable after exceeding power budget |
Yes |
| Dynamic Power Allocation |
Yes |
| PoE Power Budget |
780 W |
| Rack Space |
19" |
| Dimension (W x D x H) cm |
44 x 39.1 x 4.4 |
| Weight |
6.5 kg |
| 100-240 VAC, 50-60 Hz |
Yes |
| Max System Power Consumption (Watts) |
65 W |
| Operating Temperature |
0 ~ 45ºC |
| Storage Temperature |
40 ~ 70ºC |
| Operating Humidity (non-condensing) |
10% to 90% |
| Storage Temperature (non-condensing) |
10% to 90% |
| Environmental Regulation Compliance: WEEE |
Yes |
| Environmental Regulation Compliance: RoHS |
Yes |
| FCC Class A |
Yes |
| CE |
Yes |
| Safety Compliance: CB |
Yes |
| Safety Compliance: UL |
Yes |
